项目地址:https://github.com/coolsnowwolf/lede
参考文章:https://www.right.com.cn/FORUM/thread-3769950-1-1.html
R2S官方WIKI:http://wiki.friendlyarm.com/wiki/index.php/How_to_Build_FriendlyWrt/zh#RK3328.E5.B9.B3.E5.8F.B0
前段时间R2S软路由比较火,于是就搞了一台。闲来无事网上搜了下OpenWRT固件的编译方法,做下记录。
编译时使用普通用户登录,我习惯采用的平台是Debian 10,部分编译需要提升权限,Debian 10需要自行安装并设置sudo命令,而Ubuntu平台自带这个命令,所以更建议使用Ubuntu平台来编译。全程使用科学上网环境,否则可能因为软件包下载不全而造成编译失败。编译后的固件登录地址更改为10.192.168.254,用户名root,密码为空。
1. 搭建lean和friendlywrt编译环境
使用管理员权限更新系统软件包:
sudo apt-get update && sudo apt-get upgrade
使用管理员权限安装编译所需软件包:
sudo apt-get -y install build-essential asciidoc binutils bzip2 gawk gettext git libncurses5-dev libz-dev patch python3.5 unzip zlib1g-dev lib32gcc1 libc6-dev-i386 subversion flex uglifyjs git-core gcc-multilib p7zip p7zip-full msmtp libssl-dev texinfo libglib2.0-dev xmlto qemu-utils upx libelf-dev autoconf automake libtool autopoint device-tree-compiler g++-multilib antlr3 gperf
我使用的是虚拟机环境编译,新建了一块40G的磁盘,挂载于/mnt/sdb1目录下,逐条输入以下命令:
cd /mnt/sdb1 && git clone https://github.com/coolsnowwolf/lede
cd lede && git pull && ./scripts/feeds update -a && ./scripts/feeds install -a
cd /mnt/sdb1 && git clone https://github.com/friendlyarm/repo && sudo cp repo/repo /usr/bin/
cd /mnt/sdb1 && mkdir friendlywrt-rk3328 && cd friendlywrt-rk3328
repo init -u https://github.com/friendlyarm/friendlywrt_manifests -b master-v19.07.1 -m rk3328.xml --repo-url=https://github.com/friendlyarm/repo --no-clone-bundle
repo sync -c --no-clone-bundle
cd /mnt/sdb1/friendlywrt-rk3328 && wget -O - https://raw.githubusercontent.com/friendlyarm/build-env-on-ubuntu-bionic/master/install.sh | bash
2. 调整文件
cd /mnt/sdb1/ && cp -rf lede/feeds.conf.default friendlywrt-rk3328/friendlywrt/
由于一些依赖包缺失,我又找了一些feeds.conf.default文件的源地址加入,最终内容如下:
#src-git packages https://github.com/coolsnowwolf/packages
#src-git luci https://github.com/coolsnowwolf/luci
#src-git routing https://git.openwrt.org/feed/routing.git
#src-git telephony https://git.openwrt.org/feed/telephony.git
src-git freifunk https://github.com/freifunk/openwrt-packages.git
#src-git video https://github.com/openwrt/video.git
#src-git targets https://github.com/openwrt/targets.git
#src-git management https://github.com/openwrt-management/packages.git
#src-git oldpackages http://git.openwrt.org/packages.git
#src-link custom /usr/src/openwrt/custom-feed
src-git helloworld https://github.com/fw876/helloworld
src-git kenzok https://github.com/kenzok8/openwrt-packages
src-git small https://github.com/kenzok8/small
src-git base https://git.lede-project.org/source.git
src-git packages https://git.lede-project.org/feed/packages.git
src-git luci https://git.lede-project.org/project/luci.git
src-git routing https://git.lede-project.org/feed/routing.git
src-git telephony https://git.lede-project.org/feed/telephony.git
继续调整文件的工作:
cp -rf lede/package/lean friendlywrt-rk3328/friendlywrt/package
cp -rf lede/tools/ucl friendlywrt-rk3328/friendlywrt/tools/ && cp -rf lede/tools/upx friendlywrt-rk3328/friendlywrt/tools/
cd /mnt/sdb1/ && vi friendlywrt-rk3328/friendlywrt/tools/Makefile
将tools-y += ucl upx添加到# subdirectories to descend into段里
例:
tools-$(CONFIG_TARGET_tegra) += cbootimage cbootimage-configs下一行添加
tools-y += ucl upx
将$(curdir)/upx/compile := $(curdir)/ucl/compile添加到# builddir dependencies段里
例:
$(curdir)/cbootimage/compile += $(curdir)/automake/compile下一行添加
$(curdir)/upx/compile := $(curdir)/ucl/compile
3. 更新源码或者固件配置
cd /mnt/sdb1/friendlywrt-rk3328/friendlywrt && ./scripts/feeds update -a && ./scripts/feeds install -a
sed -i 's/192.168.2.1/10.192.168.254/g' /mnt/sdb1/friendlywrt-rk3328/friendlywrt/package/base-files/files/bin/config_generate
cd /mnt/sdb1/friendlywrt-rk3328/friendlywrt && make menuconfig
4. 选项设置
移动光标到需要选择的项目,按下空格或者Y键选择,按下N键取消,
Target System 选择 ockchip rk3328 (aarch64)
Target Images 选择 squashfs
Base system 取消 dnsmasq
选择 dnsmasq-full
由于R2S性能较弱,我仅仅保留了adguard home,smartdns以及某一上网工具,
> LuCI > 2. Modules > luci-compat 必选,否则后续插件界面错误
> Network > SSH > openssh-sftp-server 方便使用WinSCP通过SSH传送文件
> LuCI > 3. Applications > luci-app-adguardhome
> LuCI > 3. Applications > luci-app-firewall
> LuCI > 3. Applications > luci-app-smartdns
5. 编译
cd /mnt/sdb1/friendlywrt-rk3328/friendlywrt && make download -j1 V=s
cd /mnt/sdb1/friendlywrt-rk3328 && ./build.sh nanopi_r2s.mk
编译完成后的文件路径/mnt/sdb1/friendlywrt-rk3328/out。
提取出IMG文件,在Windows环境下使用BalenaEtcher软件写入SD卡,Linux环境使用命令:
sudo dd if=out/FriendlyWrt_xxxxxxxx_NanoPi-R2S_arm64_sd.img bs=1M of=/dev/sdX 文件名称和SD卡设备号根据实际情况做调整
